Best Flat Single Axis Solar Tracking System Pricelist, Companies

ZRP flat single axis solar tracking system has one axis tracking the azimuth angle of the sun. Each set mounting 10 - 60 pieces of solar panels, given a 15% to 30% production gain over fixed-tilt systems on the same size array. ZRP flat single axis solar tracking system has good power generation in low latitude regions, the effect will be not so good in high latitudes, but it can save lands in high latitude regions. Flat single axis solar tracking system is the cheapest tracking system, widely used in large-scale projects.

Send Inquiry

Product Description

📈

Higher Production Gain

Each set mounts 10 - 60 pieces of solar panels, providing a 15% to 30% production gain over fixed-tilt systems on the same size array.

🛡️

Smart Weather Protection

Equipped with sensors for wind, rain, and snow. Automatically adjusts to horizontal or tilted states to protect modules and maximize efficiency.

💰

Cost-Effective Design

The cheapest tracking system available, widely used in large-scale projects. Shorter racking heights require less space and simplify maintenance.

ZRP flat single axis solar tracking system has one axis tracking the azimuth angle of the sun. It has excellent power generation in low latitude regions and offers significant land-saving benefits in high latitude regions.

On cloud-covered days, sunlight is received as diffuse light. Our system is designed to stow horizontally to catch diffuse light, ensuring power generation even when direct beams are blocked.

Technical Specifications
System type	Single row type / 2-3 rows linked
Control mode	Time + GPS
Average tracking accuracy	0.1° - 2.0° (adjustable)
Gear motor	24V/1.5A
Output torque	5000 N·M
Tracking power consumption	5kWh/year/set
Azimuth angle tracking range	±50°
Back tracking	Yes
Max. wind resistance (Horizontal)	40 m/s
Max. wind resistance (Operation)	24 m/s
Material	Hot-dipped galvanized ≥65μm
System warranty	3 years
Working temperature	-40℃ to +80℃
Weight per set	200 - 400 KGS
Total power per set	5kW - 40kW

Frequently Asked Questions

What is the production advantage of the ZRP tracking system?

The system provides a 15% to 30% production gain compared to fixed-tilt systems by mounting 10 - 60 solar panels on a single tracking axis.

How does the system respond to extreme weather conditions?

The system features a weather station with wind, rain, and snow sensors. It returns to a horizontal state for wind resistance and enters a tilted state during rain or snow to wash the modules or prevent snow accumulation.

Is this system suitable for high-latitude regions?

While power generation is most efficient in low latitudes, the system is beneficial in high latitudes because it helps save land resources, making it a versatile option for various locations.

What makes this system cost-effective for large projects?

It is the most affordable tracking system available. Its shorter racking height requires less installation space and results in a more concentrated footprint, making operations and maintenance easier.

How does it perform on cloudy or overcast days?

On cloudy days, the system can stow horizontally to better capture diffuse light, which is more effective than facing the sun's position directly when beams are not present.

What is the tracking accuracy and range?

The system offers an adjustable average tracking accuracy of 0.1° to 2.0° with an azimuth angle tracking range of ±50°.
